fail - measured over 24664 pixels carrying ink in either image.
These results are not meaningful. This check renders a single static frame, and nothing in a test document records which moment in time its reference image was captured at - so a correct SMIL implementation and a broken one are equally likely to mismatch. Animation behaviour is covered by dedicated unit tests instead; see ctgnz/foxglove#208 for a real measurement methodology, still to be worked out.
W3C reference (context only, see #200)
Foxglove
Difference
In the difference panel, red marks pixels that
differ beyond tolerance and grey marks matching content. The tinted band, where present, is the
<text id="revision"> legend every test carries: it renders in a fallback font this
library cannot match, so it is excluded from the comparison entirely rather than failing every test.
What this test checks
The test is passed if the lightgray rectangles are exactly in the positions indicated by each of the orange rectangles when they are shown with a thick stroke. If any part of the lightgray rectangles are outside the thick stroked orange rectangles then the test has failed.
