pass - measured over 7513 pixels carrying ink in either image.
These results are not meaningful. This check renders a single static frame, and nothing in a test document records which moment in time its reference image was captured at - so a correct SMIL implementation and a broken one are equally likely to mismatch. Animation behaviour is covered by dedicated unit tests instead; see ctgnz/foxglove#208 for a real measurement methodology, still to be worked out.
W3C reference (context only, see #200)
Foxglove
Difference
In the difference panel, red marks pixels that
differ beyond tolerance and grey marks matching content. The tinted band, where present, is the
<text id="revision"> legend every test carries: it renders in a fallback font this
library cannot match, so it is excluded from the comparison entirely rather than failing every test.
What this test checks
The test passes if after five seconds, in each of the three rows, the red rectangle is in the column at the times indicated. Thus, from the document load until 2s afterwards, the red square in all three rows must be in the left column. At 2s, all three red squares must move to the right column. At 4s, the red square in the first row must move to the left column and the other two red squares must remain in the right column.
