coords-units-02-b

49.2% of the ink matches
fail - measured over 21209 pixels carrying ink in either image.

W3C reference (context only, see #200)

W3C reference (context only, see #200)

Foxglove

Foxglove

Difference

Difference
In the difference panel, red marks pixels that differ beyond tolerance and grey marks matching content. The tinted band, where present, is the <text id="revision"> legend every test carries: it renders in a fallback font this library cannot match, so it is excluded from the comparison entirely rather than failing every test.

What this test checks

In the first two tests, that validate coordinate processing, the circles should have the same center. In the following two tests, the rectangles should have the same height and width. And finally, in the last test, the 3 skewed circles should have the same radius. The rendered image should match the reference image except for the text which may show minor differences, per CSS2 rules for font selection and matching.

View the source document at W3C
