masking-path-03-b

69.3% of the ink matches
fail - measured over 48721 pixels carrying ink in either image.

W3C reference (context only, see #200)

W3C reference (context only, see #200)

Foxglove

Foxglove

Difference

Difference
In the difference panel, red marks pixels that differ beyond tolerance and grey marks matching content. The tinted band, where present, is the <text id="revision"> legend every test carries: it renders in a fallback font this library cannot match, so it is excluded from the comparison entirely rather than failing every test.

What this test checks

The test passes if: The four "Outer Clip" boxed strings must not render outside the outermost 'svg' element (the 480x360 rectangular viewport) and must continue to be clipped to this viewport if the image is zoomed in or out, or panned. The four "Inner Clip" boxed strings must not render outside the bounds of the green rectangle.

View the source document at W3C
