struct-image-03-t

55.3% of the ink matches
fail - measured over 103211 pixels carrying ink in either image.

W3C reference (context only, see #200)

W3C reference (context only, see #200)

Foxglove

Foxglove

Difference

Difference
In the difference panel, red marks pixels that differ beyond tolerance and grey marks matching content. The tinted band, where present, is the <text id="revision"> legend every test carries: it renders in a fallback font this library cannot match, so it is excluded from the comparison entirely rather than failing every test.

What this test checks

Several different images are displayed one above the other; if gamma correction is correctly performed based on the values in the gAMA chunk in the PNG file, the resulting displayed values are the same in all of the files (except for rounding error, which gives some artefacts at the right side of the lowest two images due to the very high levels of gamma correction needed for this test)

View the source document at W3C
