text-tspan-02-b

43.1% of the ink matches
fail - measured over 15552 pixels carrying ink in either image.

W3C reference (context only, see #200)

W3C reference (context only, see #200)

Foxglove

Foxglove

Difference

Difference
In the difference panel, red marks pixels that differ beyond tolerance and grey marks matching content. The tinted band, where present, is the <text id="revision"> legend every test carries: it renders in a fallback font this library cannot match, so it is excluded from the comparison entirely rather than failing every test.

What this test checks

For this test to pass the text "Not all characters in the text have a specified rotation" must be displayed in green without any red showing. If any red shows the test is a fail. Rotation values: The characters in the text "Not" must be rotated by 5,15 and 25 degrees respectively. The first 3 characters in the text "all characters" must be -10,-20 and -30 degrees respectively. Subsequent characters in the text must be each rotated by -40 degrees. All the characters in the text "text have a" must be rotated by -40 degrees. The characters in the text "in the" must be rotated by 70,60,50,40,30 and 20 degrees respectively. Note: the space in the text consumes a rotate value. All the characters in the text "specified" must be rotated by -10 degrees. All the characters in the text "rotation" must be rotated by 55 degrees.

View the source document at W3C
